GrandMA3 full-size

preview (19).png

The fundamental syntax of the grandMA2 has been preserved and extended to facilitate the new functionality.

The grandMA3 software has an elegant new system-architecture incorporating new fixture, feature and effects-handling at its very heart. These ground-breaking concepts from top industry visionaries, are presented within a refined user interface, and are designed to make practical tasks more intuitive. Selecting fixtures, adjusting values, storing presets and playing back cues should all feel familiar, but improved in many details of the process.

Better overview, faster access and more accurate information will create an improved user experience in programming and busking a show.

Fixture information is now generic and allows simpler sharing of programmed data between fixtures. We also support the new GDTF (General Device Type Format) natively, allowing fixture manufactures to ensure their own fixtures are controlled as intended.

For more details of the current software version see the software category in the product section.

grandMA3 full-size CRV

所述grandMA3 Full-size CRV(控制室版)控制台是該範圍的主打但不含顯示器翼。grandMA3 Full-size CRV專為在視線可能充滿挑戰的控制室中使用而設計,具有3個額外的外部監視器端口,以便容易地放置外部第三方觸控螢幕,而不會失去grandMA3 Full-size控制台的功能。

更多資訊



所述grandMA3 Full-size CRV(控制室版)控制台是該範圍的主打但不配給顯示器翼。grandMA3 Full-size CRV專為在視線可能充滿挑戰的控制室中使用而設計,具有3個額外的外部監視器端口,以便容易地放置外部第三方觸控螢幕,而不會損害grandMA3 Full-size控制台的功能。

可分配的電平輪部分和專用的主播放組可讓您輕鬆使用強大的功能。添加120個物理播放和16個可分配的x鍵,grandMA3 Full-size控制台提供MA Lighting迄今為止生產的最靈活的播放平台。

grandMA3 Full-size CRV控制台標配12,288個控制參數,確保它是世界上最負盛名的娛樂照明應用的理想基礎平台。使用額外的grandMA3 Processing units,系統規模可擴展至250,000個參數。

三個訊息螢幕是上下相關的,專用於為grandMA3控制台播放和編碼器硬體提供反饋和選項。

grandMA3 Full-size CRV與grandMA2和grandMA3軟體兼容。硬體經過人體工程學優化,默認情況下可以視為靜默版本。

特徵
  • 與grandMA3處理單元相關的每個會話實時控制多達250,000個參數

  • 6個DMX輸出,1個DMX輸入

  • 3個內部信箱多點觸控螢幕

  • 2個內部多點觸控命令螢幕

  • 可以連接5個外部多點觸控螢幕

  • 2個多功能水平輪

  • 2個多功能單編碼器

  • 71個旋轉RGB背光編碼器

  • 5個背光雙編碼器

  • 30個背光電動60mm推桿

  • 120個單獨的播放

  • 16個可分配的x鍵

  • 集成式鍵盤抽屜

  • 內置不間斷電源(UPS)

  • 3個etherCON接孔,6個USB接孔

  • 2個背光電動A / B推桿100mm

  • 單獨的背光和可調光靜音(無點擊)鍵


grandMA2 Compatibility

The grandMA3 control consoles are compatible with shows created on grandMA2 consoles. Where features allow, existing shows can be exported from grandMA2 software 3.4 and later, for use in all grandMA3 console models.


All grandMA3 console models (except the grandMA3 onPC command wing) incorporate a fully featured Mode2, which runs native grandMA2 software.
